Nguồn gốc:
Trung Quốc
Hàng hiệu:
WINNER
Chứng nhận:
ISO9100
Số mô hình:
BC010
Băng hình
Băng hình
Băng hình
Gold-plated Beryllium Copper Wire is a high-strength copper alloy containing a small percentage of cadmium, which significantly enhances its mechanical properties while retaining good electrical conductivity. This wire is primarily used in applications where both electrical conductivity and high tensile strength are required.
| Specific Resistivity | 7.68 µOhm·cm²/cm |
| Commercial Resistance Tolerance (On Sizes below 0.020) | 3.00 % |
| Thermal Electromotive Force (EMF) Vs Copper | -0.014 |
| Specific Resistance | 46.200 Ohm·cm/ft |
| Temperature Coefficient of Resistance (0 to 100 Degree Celsius (ºC) Temperature) | 0.0015 Ohm/Ohm/ºC |
| Density | 8.25 g/cm³ |
| Youngs Modulus | 18 x 106 psi |
| Specific Heat at 20 Degree Celsius (ºC) Temperature | 0.100 cal/g |
| Thermal Conductivity | 1.069000 W/cm/ºC |
| Coefficient of Linear Expansion | 17.6 x 10-6 in/in ºC |
| Melting Point | 865.00 ºC |
